Highspot Wireless

Introduction

The Highspot Wireless offers over 600 lumens with a range of lens types from ultra high rack to ultra wide ensuring its suitability in a range of applications from high level logistics and light industrial through to multi storey car parks. The polycarbonate housing and diffuser is both impact resistant and IP65 rated whilst the lensed optic ensures that emergency spacing can be maximised reducing the number of luminaires required and installation cost relative to integral emergency solutions.

The Highspot Wireless is compatible with our React-Link system providing automated testing and central reporting of test results and failures substantially reducing ongoing maintenance costs of your emergency installation.

HIGHSPOT WIRELESS complies with:

UKCA | CE | IP65

Recommended applications:

Canteen | Commercial / Offices | Corridor | Education | Food Production | Healthcare / Social Housing | Hotel / Leisure | Industrial / Manufacturing | Kitchen | Office | Parking / Exterior | Retail | Stairwell | Store Room | Toilet | Transport | Warehousing

Specification

Construction

  • Housing: Injection moulded polycarbonate
  • Finish: Matt grey
  • Diffuser: Injection moulded clear polycarbonate
  • Lens: Injection moulded PMMA lens
  • IK09
  • IP65

Environmental

  • Designed to allow simple replacement of components with commonly available tools in compliance with the Eco Design Directive, please see the installation leaflet for maintenance instructions.
  • All critical components are mounted on a single tray for simple end of life repair or upgrade.
  • Powered by European branded drivers and emergency modules ensuring replacement parts are easily sourced.
  • Every luminaire is labelled with a unique ID number allowing easy identification of spare parts for the lifetime of the product.
  • Contains no single use plastics or polystyrene packaging.
  • Supplied in plain card boxes with paper tape ensuring packaging is easily recycled.
  • Designed to allow simple disassembly for end of life recycling.
  • UK based manufacturing providing local support throughout the product lifetime and minimising transportation miles.

Emergency

  • Optional Reacta-Link wireless emergency for automated centralised reporting.
  • Optional Reacta-Control wireless emergency for automated centralised reporting.

Control

  • Optional compatibility with a range of dimming systems including DALI, DSI and Switch Dimming

Installation

  • Suitable for conduit installation
  • Suitable for surface installation
5 year extended warranty available on most products.
Arrow right

Product Images

Technical

Highspot Wireless

Highspot Wireless

Ordering

Luminaires

Code Description Power
HSP LED NM3 LA3RC UW Highspot Wireless, 644llm, Lithium Non Maintained, Reacta-Control 3 Hour, Ultra Wide 4.4W
HSP LED NM3 LA3RC OA Highspot Wireless, 640llm, Lithium Non Maintained, Reacta-Control 3 Hour, Open Area 4.4W
HSP LED NM3 LA3RC UHR Highspot Wireless, 655llm, Lithium Non Maintained, Reacta-Control 3 Hour, Ultra High Rack 4.4W
HSP LED NM3 LSTR UW Highspot Wireless, 644llm, Lithium Non Maintained, Reacta-Link 3 Hour, Ultra Wide 4.4W
HSP LED NM3 LSTR OA Highspot Wireless, 640llm, Lithium Non Maintained, Reacta-Link 3 Hour, Open Area 4.4W
HSP LED NM3 LSTR UHR Highspot Wireless, 655llm, Lithium Non Maintained, Reacta-Link 3 Hour, Ultra High Rack 4.4W
All products are supplied with a 5 year battery warranty

Miscellaneous

Code Description
LSF Low Smoke Zero Halogen

Downloads

Installation guide (Download PDF) Product Datasheet (Download PDF) Revit Files Dialux Files Relux Files
